Devco’s process heater line has a heater to meet your specific heat requirement.
Devco offers standard and custom designed heating systems. Our standard packaged units are delivered quickly and come complete with burner, fuel train, and burner management system (BMS).
Devco’s custom heating systems are thoroughly designed to meet your special application’s requirements, from a unique process fluid to a specialized BMS that meets your information needs.
All of Devco’s process heaters are capable of achieving optimal thermal efficiency up to 90% net thermal efficiency. This means minimal energy consumption to the consumer.
All of Devco’s heaters are available with state-of-the-art low emission technology, adhering to the required standards of today’s eco-friendly world.
Devco’s in house, state-of-the-art computerized process and mechanical programs allow Devco to provide the optimal heater for your special application.
Devco’s heaters are applicable to a wide range of process fluids from water to the unique (e.g. carbon tetrachloride), mechanical applications from 0 – 10,000 PSIG pressure and -320 to 1600 deg F. temperature.
HELIFLO Direct Fired Heater
The Devco HELIFLO direct fired heater ranges in duty from 0.25 to 100 MMBtu/Hr. It can heat a variety of process media including gas, liquids, and multi-phase fluids. It is available in a horizontal, vertical, and down-fired configuration.
The Devco Indirect Heater
The Devco indirect heater utilizes a proven concept that has been the standard since the 1930’s. An intermediate bath media (e.g. water, eutectic salt, hot oil) is employed to immerse and separate the process coil from the firebox. The heat is transferred from the firebox to the bath media which in turn transfers it to the process coil. The process coil is totally isolated from any direct flame and/or combustion product contact associated with conventional direct fired heaters. Devco’s indirect heaters range from 0.1 to 25 MMBtu/Hr.
Convective Heaters – Kineflo, Equiflo & Convecto
The Devco KINEFLO heater is a convective heater designed with a controlled separate heat transfer section bringing a unique solution to sensitive heating applications. The Devco KINEFLO heater design eliminates the conventional radiant heat transfer section. Result is the process fluid is primarily heated by safe forced convection. This is achieved with separate partitioned combustion and heat exchange sections, designed for optimum heat transfer control. Radiant heat transfer is virtually eliminated by quenching the combustion products to a maximum 1600 deg F. prior to entering the heat exchange section. Devco KINEFLO heaters range from 0.5 to 100.0 MMBtu/Hr.
